Tensile Testing Machine

Price 68000.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Tensile Testing Machine Specification

Display Type
Digital Display

Shape
Vertical Rectangular

Power Supply
Single Phase AC

Temperature Resistance
Ambient to 40C

Control Type
Digital Microprocessor Based

Features
Heavy Duty Construction, Easy Operation, Durable Finish, Overload Protection

Accuracy
1% of Indicated Load

Speed Range
0.5 to 500 mm/min

Type
Tensile Testing Machine

Dimension (L*W*H)
800 x 550 x 1800 mm

Equipment Type
Mechanical Testing Machine

Equipment Materials
Mild Steel Body, Stainless Steel Fixtures

Power
1.5 kW

Voltage
230 V AC

Material
Mild Steel

Application
Testing Tensile Strength of Materials

Test Standards Supported
ASTM, ISO, IS

Test Modes
Tensile, Compression, Bending, Shear

Net Weight
Approx. 320 kg

Ambient Humidity
20%-80% RH

Test Capacity
5 kN to 100 kN (Model Dependent)

Grip Type
Self Centering Wedge Grips

Crosshead Travel
Up to 1000 mm

Finish Type
Powder Coated

Safety Features
Emergency Stop, Over-Travel Protection

Load Cell Type
Strain Gauge Type

Data Output
USB, RS-232 Interface

Maximum Elongation
650 mm

Optional Accessories
Extensometer, PC Software, Printer

Tensile Testing Machine Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Cash Advance (CA), Cash in Advance (CID)

Supply Ability
1 Piece Per Day

Delivery Time
2 Week

Sample Available
Yes

Packaging Details
1

Main Export Market(s)
Asia

Main Domestic Market
Goa, Kerala, Andhra Pradesh, Mizoram, Meghalaya, Manipur, Bihar, Jharkhand, Odisha, Punjab, Assam, Delhi, Dadra and Nagar Haveli, Andaman and Nicobar Islands, Arunachal Pradesh, Chhattisgarh, Haryana, Himachal Pradesh, Jammu and Kashmir, Madhya Pradesh, Maharashtra, Nagaland, Rajasthan, Sikkim, Tamil Nadu, Telangana, Tripura, Pondicherry, Uttar Pradesh, Uttarakhand, West Bengal, All India, South India, Central India, West India, North India, East India, Gujarat, Karnataka, Lakshadweep, Chandigarh, Daman and Diu

Certifications
1

About Tensile Testing Machine

Specification:

Floor mounted, vertical type, two column construction specially manufactured for various applications.
Tensile Testing Machinesare designed for determining the Tensile Strength and Elongation of a host of materials like ferrous and non ferrous materials, cables & conductors, Plastic, PVC, Rubber specimens, paper, plywood etc.

Our Tensile Testing Machines are also capable for conducting compression, Cross breaking and Shear tests thus making them more versatile with a few additional attachments.
Tensile Testing Machines are available in various capacities depending upon the requirements right from 5 kgf to 10 Tonnes ensuring 1% accuracy in test results.
We assure high accuracy, sensitivity, reliability, consistency, repeatability
and excellent workmanship.
Tensile Testing Machines are backed up by prompt and effective after service by a team of factory trained technicians.
Our machines are available in KGF/ kN/N as per your specific requirements.

Tensile Testing Machines are also available with State of Art Electronic
Microprocessor based Digital Indicator systems with PC and Printer.
Horizontal Models and Computerized versions are also in our
range of production.

Technical Specifications

MODEL	ZI 7007-A	ZI 7007-B	ZI 7007-C
Capacities (Kgf)	250	500	1000
Least Count	0.1 gms.	0.1 gms.	0.1 kgf.
Traverse Speed(mm/ min)	500 and 100	100	100
Grip Separation
Minimum	25 mm	25 mm	25 mm
Maximum	1000 mm	1000 mm	750 mm
Power Requirement	3ph440V 50 c/s AC	3ph440V 50 c/s AC	3ph440V 50 c/s AC
Over-travel SafetySwitches	Incorporated	Incorporated	Incorporated
Load ElongationRecorder	Optional	Optional	Optional

MODEL	ZI 7007-D	ZI 7007-E	ZI 7007-F
Capacities (Kgf)	2500	5000	10000
Least Count	0.1 kgf.	0.1 kgf.	0.1 kgf.
Traverse Speed(mm/ min)	100	100	25 and 12.5
Grip Separation
Minimum	25 mm	25 mm	25 mm
Maximum	750 mm	600 mm	500 mm
Power Requirement	3ph440V 50 c/s AC	3ph440V 50 c/s AC	3ph440V 50 c/s AC
Over-travel SafetySwitches	Incorporated	Incorporated	Incorporated
Load ElongationRecorder	Optional	Optional	Optional

Versatile Testing Capabilities

Designed for tensile, compression, bending, and shear tests, this machine accommodates a wide array of material testing applications. The speed range of 0.5 to 500 mm/min and accuracy within 1% of indicated load ensure dependable outcomes for quality assurance and research purposes.

Robust and User-Friendly Design

With its heavy-duty construction, self-centering wedge grips, and digital display, the equipment offers easy operation and long-term durability. Overload and over-travel protection, along with an emergency stop function, reinforce laboratory safety standards.

Comprehensive Connectivity and Accessories

The machine supports USB and RS-232 connectivity for efficient data export. Optional accessories-such as an extensometer, PC software, and printer-enhance versatility for various testing protocols and detailed result analyses.

FAQ's of Tensile Testing Machine:

Q: How does the Tensile Testing Machine ensure accurate load measurement?

A: The machine uses a strain gauge-type load cell which delivers precise measurement of applied loads, with an accuracy of 1% of the indicated value, ensuring reliable data for a variety of testing applications.

Q: What materials and standards can be tested with this device?

A: It is suitable for testing the tensile strength of materials including mild steel and other metals, with compatibility for ASTM, ISO, and IS test standards for broad industry compliance.

Q: When should I use the emergency stop and what safety features are included?

A: The emergency stop should be used immediately if the specimen fails or if unexpected issues arise during testing. Additional safety features include overload protection and over-travel protection to safeguard both the user and equipment.

Q: Where can test data be exported and how?

A: Test data can be exported via USB or RS-232 interface, allowing seamless integration with computers, data loggers, or printers for thorough documentation and analysis.

Q: What is the process for conducting a tensile test using this machine?

A: Place the specimen in the self-centering wedge grips, configure the desired test mode on the digital microprocessor control, and initiate the test. The machine measures and records parameters such as load, elongation, and failure point.

Q: How does the robust construction benefit my laboratory or facility?

A: The heavy-duty mild steel body and stainless-steel fixtures ensure lasting durability and stability even during intensive testing cycles, reducing downtime and maintenance costs.

Q: What optional accessories are available to enhance testing capabilities?

A: Available options include an extensometer for precise strain measurement, dedicated PC software for advanced data handling, and a printer for direct hardcopy results, making the system adaptable to various testing needs.
