Liquid Limit Device

Price 3000.00 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Liquid Limit Device Specification

Motor Power
Manual operated (No motor, Hand Cranked)

Surface
Polished brass and coated metal

Lifting Height
10 mm (standard drop height)

Lifting Speed
14 revolutions per 30 seconds

Product Type
Liquid Limit Device

General Use
Testing the plasticity characteristics of soil

Material
Brass bowl, Metal base, Bakelite/Plastic handle

Type
Hand Operated Casagrande type

Capacity
Single soil sample per test

Weight (kg)
Approx. 2.5 - 5 kg

Computerized
No

Automatic
No, Manual operation

Control System
Mechanical/Manual control

Method
Casagrande Method

Dimension (L*W*H)
Approx. 250 x 150 x 110 mm

Feature
Removable brass bowl, adjustable height, counter and grooving tool

Color
Golden brass with black/ivory finish

Bowl Diameter
Approx. 55 - 60 mm

Packaging
Sturdy export-quality box

Operating Temperature Range
5°C to 40°C

Accessories
Grooving tool, gauge block, instruction manual

Grooving Tool
Standard ASTM and IS grooving tools included

Counter Type
Mechanical resettable counter

Conforming Standards
IS 2720 (Part V), ASTM D4318, BS 1377

About Liquid Limit Device

Product Details:

Minimum Order Quantity	01 Piece
Brand	Matest
RPM	120
Power Supply	230 V A.C.,Single Phase, 50 Cycles
Material for Construction	Stainless steel

Same as ZI 3006 but fitted with a motor geared down to give approximately 120 rpm.

Precision Soil Testing Instrument

This Liquid Limit Device features a hand-operated design with a mechanical resettable counter, meeting IS, ASTM, and BS standards for evaluating soil plasticity. The robust construction includes a polished brass bowl, metal base, and Bakelite or plastic handle, ensuring durability and accuracy in laboratory and field settings. Its removable brass bowl and adjustable height settings simplify cleaning and calibration, making it a reliable choice for consistent soil testing results.

Comprehensive Accessory Kit Included

Each unit comes complete with essential accessories: standard ASTM and IS grooving tools, a gauge block, and a clear instruction manual. All components are housed in a sturdy, export-quality box for added portability and protection. Designed for immediate use, the kit streamlines the soil testing process, supporting both novice and experienced users in measuring the liquid limit quickly and accurately.

Manual Operation for Dependable Results

Operating entirely without electricity, this device utilizes a hand crank to lift and drop the brass bowl at a standard lifting height and rate. The mechanical counter provides resettable, reliable data collection with every test. Ideal for environments without a stable power supply, the Liquid Limit Device enables laboratories, educational institutes, and field teams to perform standardized soil consistency analysis efficiently and conveniently.

FAQ's of Liquid Limit Device:

Q: How is the Liquid Limit Device operated during testing?

A: The device is operated manually using a hand crank, which lifts and drops the brass bowl at a specific height (10 mm) and speed (14 revolutions per 30 seconds). The mechanical counter tracks the number of drops, allowing precise monitoring without the need for external power.

Q: What standards does this Liquid Limit Device comply with?

A: It conforms to IS 2720 (Part V), ASTM D4318, and BS 1377 standards, ensuring compatibility with major geotechnical soil testing protocols used worldwide.

Q: When should I use this device?

A: The Liquid Limit Device is used whenever you need to determine the liquid limit of a soil sample, which is critical for classifying soil type and understanding its engineering behavior during construction or research projects.

Q: Where can this device be used effectively?

A: This device is suitable for use in laboratories, field testing facilities, educational institutions, and by soil testing service providers. Its manual operation ensures functionality in locations with limited or no electrical supply.

Q: What process does the device follow to test soil plasticity?

A: A small amount of soil is placed in the brass bowl, a groove is made using the provided tool, and the device is cranked. The bowl is repeatedly dropped until the groove closes at a specified number of drops, determining the soil's liquid limit by the Casagrande method.

Q: What are the benefits of using a mechanical resettable counter?

A: The mechanical counter allows for precise, repeatable measurements, helping reduce human error and aiding efficient documentation and consistency across multiple tests.

Q: What accessories are included with the Liquid Limit Device?

A: Each device comes with standard ASTM and IS grooving tools, a gauge block for calibration, a detailed instruction manual, and is packaged in a durable, export-quality box for safe transport and storage.
