Swell Test Apparatus

Price 40000.00 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Swell Test Apparatus Specification

Product Type
Testing

General Use
Soil Test

Material
Other

Weight (kg)
30 Kilograms (kg)

Computerized
No

Automatic
No

Control System
Manual

Cooling System
Other

Method
Other

Dimension (L*W*H)
60*40*60 Inch (in)

Color
Green

Warranty
1 year

Swell Test Apparatus Trade Information

Minimum Order Quantity
1 Piece

FOB Port
MADURAI

Payment Terms
Cash Advance (CA), Cash in Advance (CID)

Delivery Time
1 Week

Main Export Market(s)
Asia, Africa

Main Domestic Market
All India, South India, Central India, West India, North India, East India, Gujarat, Karnataka, Kerala, Lakshadweep, Mizoram, Meghalaya, Manipur, Andhra Pradesh, Bihar, Chandigarh, Daman and Diu, Goa, Jharkhand, Odisha, Punjab, Assam, Delhi, Dadra and Nagar Haveli, Andaman and Nicobar Islands, Arunachal Pradesh, Chhattisgarh, Haryana, Himachal Pradesh, Jammu and Kashmir, Madhya Pradesh, Maharashtra, Nagaland, Rajasthan, Sikkim, Tamil Nadu, Telangana, Tripura, Pondicherry, Uttar Pradesh, Uttarakhand, West Bengal

About Swell Test Apparatus

Product Details:

Minimum Order Quantity	1 Piece
Capacity	50 kN
Material for Construction	Stainless steel
Diameter	100 mm
Thickness	12.7 mm

It is designed to determine the swelling pressure developed by soil specimens moulded to desired densities at knows moisture contents when soaked in water. The load applied to restrain the swelling is transferred to a load measuring proving ring through a perforated swell plate and a load transfer bar. The proving ring is attached to the lead screw of hand operated load frame. A soaking tank is provided for saturating the specimen and the base of the mould has channels and radial grooves with connecting holes it consists one each.

Other Details:

ZI 3069-1: Load Frame, Hand Operated, Capacity 50 KN (5,000 kgf)
ZI 3069-2: Mould, 100mm dia x 127.3mm height (1,000ml volume)with base plate and collar
ZI 3069-3
Proving Ring, with integral boss, high sensitivity 2.5KN(250 Kgf) capacity
ZI 3069-4: Dial Gauge , 25 mm travel, 0.01mm least countLid receiver in G.I. frame for 300 mm dia x 450 mm diasieves
ZI 3069-5: Perforated swell plate, 100 mm dia x 16 mm thick
ZI 3069-6: Spencer, 100 mm dia x 12.7 mm thick
